Cudy GS105D network switch Unmanaged Gigabit Ethernet (10/100/1000) Black
Technical specifications
| Package type | Box |
|---|---|
| Storage temperature (T-T) | -40 – 70 °C |
| Weight | 52 g |
| Height | 24 mm |
| Cables included | DC |
| Power source | DC |
| Package weight | 137 g |
| LED indicators | Power |
| LED indicators | Activity |
| AC input voltage | 100 – 240 V |
| LED indicators | Link |
| Depth | 52.5 mm |
| Operating temperature (T-T) | 0 – 40 °C |
| Input current | 0.55 A |
| Auto MDI/MDI-X | Yes |
| Power over Ethernet (PoE) | No |
| Rack mounting | No |
| Width | 88 mm |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| AC input frequency | 50/60 Hz |
| Operating relative humidity (H-H) | 10 – 90% |
| Package height | 57 mm |
| Product colour | Black |
| Package depth | 88 mm |
| Package width | 92 mm |
| Networking standards | IEEE 802.3x |
| Storage relative humidity (H-H) | 5 – 90% |
| Manual | Yes |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.3ab |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3i |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Full duplex | Yes |
| Switching capacity | 10 Gbit/s |
| Plug and Play | Yes |
| Power connector | DC-in jack |
| Jumbo frames support | Yes |
| Power supply included | Yes |
| Copper ethernet cabling technology | 10BASE-T |
| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Copper ethernet cabling technology | 100BASE-TX |
| Packet buffer memory | 0.375 MB |
| MAC address table | 2048 entries |
| Copper ethernet cabling technology | 1000BASE-T |
| Warnings | Ensure the unit is adequately ventilated during operation. |
| Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
| Warnings | Do not open the case or try to repair it yourself. |
| Half duplex | Yes |
| Cable types supported | Cat3 |
| Jumbo frames | 15000 |
| Cable types supported | Cat5 |
| Cable types supported | Cat5e |
| Auto-negotiation | Yes |
| Store-and-forward | Yes |
| Forwarding rate | 7.44 Mpps |
| Bandwidth | 1 Gbit/s |
| DC input voltage | 5 V |
