Description
Intel Xeon Gold 6526Y processor 2.8 GHz 37.5 MB Tray
Technical specifications
| Processor cache | 37.5 MB |
|---|---|
| Cooler included | No |
| Memory channels | Octa-channel |
| Processor boost frequency | 3.9 GHz |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Discrete graphics card model | Not available |
| Mode-based Execute Control (MBE) | Yes |
| PCI Express slots version | 5.0 |
| Maximum internal memory supported by processor | 4 TB |
| Processor operating modes | 64-bit |
| Processor family | Intel® Xeon® Gold |
| Intel Trusted Execution Technology | Yes |
| Launch date | Q4'23 |
| Discrete graphics card | No |
| Supported instruction sets | AMX |
| Maximum internal memory | 4 TB |
| Market segment | Server |
| Processor threads | 32 |
| Status | Launched |
| Supported instruction sets | AVX-512 |
| Processor ARK ID | 237560 |
| Supported instruction sets | AVX 2.0 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Number of UPI links | 3 |
| Intel® Run Sure Technology | Yes |
| On-board graphics card | No |
| Memory types supported by processor | DDR5-SDRAM |
| Intel® Boot Guard | Yes |
| Supported instruction sets | SSE4.2 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| On-board graphics card model | Not available |
| Processor cores | 16 |
| Processor model | 6526Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Speed Shift Technology | Yes |
| ECC | Yes |
| Processor manufacturer | Intel |
| Maximum number of PCI Express lanes | 80 |
| Scalability | 2S |
| Processor socket | LGA 4677 (Socket E) |
| Thermal Design Power (TDP) | 195 W |
| Memory clock speeds supported by processor | 5200 MHz |
| Supported instruction sets | AVX |
| Tcase | 82 °C |
| Embedded options available | Yes |
| Intel® OS Guard | Yes |
| Processor codename | Emerald Rapids |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Processor base frequency | 2.8 GHz |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® UPI Speed | 20 GT/s |
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Warnings | Do not disassemble the processor or attempt to repair it yourself. |
| Warnings | Avoid direct contact with water and high humidity. |
| Warnings | The product should be used in accordance with the manufacturer's instructions to avoid damage. |
| Intel® On Demand Feature Activation | Yes |
| Package carrier | E1B |
| Servicing status | Baseline Servicing |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Use conditions | Server/Enterprise |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| DTS Max | 99 °C |
| Intel® Speed Select Technology – Base Frequency (Intel® SST-BF) | Yes |
| High priority cores | 4 |
| Intel® Trust Domain Extensions (Intel® TDX) | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Processor generation | Intel Xeon Scalable 5th Gen |
| Intel® Total Memory Encryption – Multi Key | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Low priority cores | 12 |
| Low priority core frequency | 2.6 GHz |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Maximum Enclave Size Support for Intel® SGX | 128 GB |
| High priority core frequency | 3 GHz |
| Intel® QuickAssist Software Acceleration | Yes |
