Description
Synology RackStation RS1619XS+ NAS/storage server Rack (1U) Intel® Xeon® D D-1527 8 GB DDR4 0 TB DiskStation Manager Black
Technical specifications
| Certification | EAC VCCI RCM FCC CE BSMI |
|---|---|
| Warnings | Do not dismantle the appliance yourself. |
| Warnings | Do not dispose of the device in the regular rubbish bin. The product requires special disposal. |
| Warnings | Avoid contact with liquids. |
| Compliance certificates | RoHS |
| PCI Express slots version | 3.0 |
| Product colour | Black |
| Hot-swap drive bays | Yes |
| Processor lithography | 14 nm |
| Chassis type | Rack (1U) |
| Execute Disable Bit | Yes |
| Intel TSX-NI | Yes |
| LED indicators | Status |
| Installed storage drive type | No |
| LED indicators | Power |
| Intel TSX-NI version | 1.00 |
| Wake-on-LAN ready | Yes |
| Supported storage drive types | HDD & SSD |
| Power supply location | Built-in |
| Server operating systems supported | Windows Server 2016 |
| Power consumption (HDD standby) | 34.78 W |
| Power consumption (typical) | 68.68 W |
| Intel 64 | Yes |
| Browser supported | Chrome, Firefox, Internet Explorer 10+, Safari 10+ |
| Web-based management | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor manufacturer | Intel |
| Conflict-Free processor | Yes |
| Processor ARK ID | 91195 |
| CPU configuration (max) | 1 |
| Memory channels supported by processor | Dual |
| PCI Express slots version | 2.0 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| AC input voltage | 100 – 240 V |
| Reset button | Yes |
| Ethernet LAN data rates | 100 Mbit/s |
| Cooling type | Active |
| Ethernet LAN data rates | 10 |
| LED indicators | HDD |
| Device class | Small & Medium Business |
| Processor boost frequency | 2.7 GHz |
| Windows operating systems supported | Windows 7 |
| LED indicators | Alarm |
| Backup features | iSCSI LUN |
| Height | 44 mm |
| Intel® Secure Key | Yes |
| Scalability | 1S |
| Harmonized System (HS) code | 84714100 |
| Supported network protocols | CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP) |
| Storage drives installed | No |
| Thermal Monitoring Technologies | Yes |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Storage drive interface | Serial ATA, Serial ATA II, Serial ATA III |
| Maximum RAM supported | 64 GB |
| Ethernet LAN | Yes |
| Expansion ports quantity | 1 |
| PCI Express configurations | 1×4 |
| Processor code | SR2DK |
| Intel® OS Guard | Yes |
| PCI Express configurations | 1×8 |
| Depth | 518.6 mm |
| Wi-Fi | No |
| PCI Express configurations | 1×16 |
| Processor package size | 37.5 x 37.5 mm |
| Windows operating systems supported | Windows 10 |
| Cables included | AC |
| Ethernet LAN data rates | 1000 Mbit/s |
| Backup features | Cloud |
| Width | 480 mm |
| Backup function | Yes |
| Thermal Design Power (TDP) | 35 W |
| Processor socket | BGA 1667 |
| ECC supported by processor | Yes |
| Power supply unit (PSU) capacity | 150 W |
| Number of power supply units | 2 |
| Idle States | Yes |
| Storage drive sizes supported | 2.5 |
| RAID support | Yes |
| Processor cores | 4 |
| Processor model | D-1527 |
| Supported file systems | Fat |
| RAID levels | 6 |
| Processor cache | 6 MB |
| RAID levels | 5 |
| Intel Trusted Execution Technology | Yes |
| Number of storage drives supported | 4 |
| RAID levels | 1 |
| Supported file systems | HFS+ |
| RAID levels | 0 |
| Multilingual support | Yes |
| Processor threads | 8 |
| Maximum internal memory supported by processor | 128 GB |
| AC input frequency | 50 – 60 Hz |
| Storage drive capacity | 0 GB |
| Internal memory | 8 GB |
| Noise level | 39.3 dB |
| Mac operating systems supported | Mac OS X 10.11 El Capitan |
| Fan diameter | 4 cm |
| UART | Yes |
| RAID levels | JBOD |
| Storage drive sizes supported | 3.5" |
| Number of M.2 (M & B) slots | 2 |
| Supported file systems | BTRFS |
| Total installed storage capacity | 0 TB |
| Link aggregation | Yes |
| Processor cache type | L3 |
| Operating system installed | DiskStation Manager |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 5 – 35 °C |
| Stepping | V2 |
| Access Control List (ACL) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Quick installation guide | Yes |
| Operating altitude | 0 – 5000 m |
| Weight | 8.16 kg |
| Memory slots | 4 |
| Mac operating systems supported | Mac OS X 10.13 High Sierra |
| On/off switch | Yes |
| Memory types supported by processor | DDR3-SDRAM |
| Supported file systems | ext4 |
| RAID levels | 10 |
| Intel Enhanced Halt State | Yes |
| Maximum number of PCI Express lanes | 32 |
| Intel® Turbo Boost Technology | 2.0 |
| Mac operating systems supported | Mac OS X 10.12 Sierra |
| Supported file systems | ext3 |
| Supported file systems | NTFS |
| Processor operating modes | 64-bit |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Memory types supported by processor | DDR4-SDRAM |
| Operating relative humidity (H-H) | 5 – 95% |
| Processor series | Intel Xeon D-1500 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB port | Yes |
| Internal memory type | DDR4 |
| Embedded options available | Yes |
| Mac operating systems supported | Mac OS X 10.14 Mojave |
| Ethernet LAN (RJ-45) ports | 4 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Processor frequency | 2.2 GHz |
| iSCSI support | Yes |
| Processor codename | Broadwell |
| On-board graphics card model | Not available |
| Processor family | Intel® Xeon® D |
| Security algorithms | SSL/TLS |
| Number of fans | 2 fan(s) |
| Security algorithms | SSH |
| Enhanced Intel SpeedStep Technology | Yes |
| Type | NAS |
| Security algorithms | HTTPS |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
